Specifications
| Model No. | D6 | D4 |
|---|---|---|
| Pixel Pitch | 6.25mm | 4.615mm |
| LED Type | SMD2727 | SMD1921 |
| Panel Resolution(W*H) | 80*80 | 108*108 |
| Scan Mode | 1/5 | 1/9 |
| LED Brand | Nation star | Nation star |
| Cabinet Size(W*H) | 500*500*72mm | 500*500*72mm |
| Panel Material | die-casting aluminum | die-casting aluminum |
| IP Ratings | IP65(Front/Rear) | IP65(Front/Rear) |
| Loading Ability | 1000kg/sqm | 1000kg/sqm |
| Refresh Rate(Hz) | 2000Hz | 2000Hz |
| Bringthness(nits) | 1800nits~5000nit | 1800nits~5000nit |
| MAX Power Consumption(W) | 200 W/panel | 200W/panel |
| Color Processing(bit) | 16 bit | 16 bit |
| Viewing Angle(H/V) | 140°/110° | 140°/110° |
| Input Voltage(V) | AC 100~240;50/60Hz | AC 100~240;50/60Hz |
| Operating Temperature(℃) | -20~50℃ | -20~50℃ |
| Life Time | >100000 Hours | >100000 Hours |
Product Description
High security
Designers choose a block of aluminum plate as the screen body, without fans, truly natural cooling and no noise.
Heat dissipation and withstand voltage
Black face mask with anti-slip wear; front and back Protection Level is IP65, it can be adapt to various occasions.
installation maintenance
The installation screen without tools, the screen body comes with cable to reduce the process; screen maintenance of a single box can be removed directly from the vertical, as much as possible to save time and installation and maintenance costs.
Application
Business : Shopping Mall, Stage, Bar，Concert
Live broadcast: Gym, Stadium, Concert, Sport Match, Competition, Gov publication etc.
Rental business:Event, Fashion&Auto Show, Entertainment, Wedding, Party etc.
